d - 60 mm

D - 145 mm

H - 45 mm

d₁ - 85 mm

D₁ - 100 mm

H₁ - 35 mm

r_1,2 - min. - 0.6 mm

r_3,4 - min. - 0.6 mm

a - 168 mm

J - 120 mm

H - 8.8 mm

d_a - min. - 82 mm

D_a - max. - 100 mm

r_a - max. - 0.6 mm

Basic dynamic load rating - C - 85 kN

Basic static load rating - C₀ - 216 kN

Fatigue load limit - P_u - 8 kN

Limiting speed - 1600 r/min

Preload - 4700 N

Frictional moment - 2 N·m

Static Axial rigidity - 1400 N/micron

Mass bearing - 4.3 kg

Required attachment bolt size - M8

Number of attachment bolts - 8

• Model Number: BEAM 060145-2RS
• Inner Diameter：60mm Outer Diameter：145mm Width：45mm
• Type：Thrust Ball Bearings
• Update date：2025-04-22
• Application:Other Measurements,directional control valve,industry test,noise reduction equipment,Medical equipment,root canal filling,surgical instruments,transistor fittings,oral medical device,walking Food processing machinery and equipment,van
• Similar models:SKF BEAM060145-2RS SKF BEAM060145-2RZ
• BEARING POWER International Trading Co.,Ltd. specialize in BEAM060145-2RS products，there is large inventory of SKF BEAM 060145-2RS . We has been built up long-term cooperation with SKF company, could make a bulk order of the BEAM 060145-2RS Which SKF BEAM060145-2RS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  164127X/164200XP	127	200,025	93,67	Gamet	Tapered Roller Bearings
  22248RHA	240	440	120	KOYO	Spherical Roller Bearings
  3781/3730	49,2125	93,26372	30,1625	AST	Tapered Roller Bearings
  4T-1985/1930	28,575	56,896	19,845	NTN	Tapered Roller Bearings
  4311	55	120	43	KOYO	Deep Groove Ball Bearings
  54224	120	170	71,6	NSK	Thrust Ball Bearings
  626-2RSH	19	6	6	SKF	Deep Groove Ball Bearings
  7072 ADF	360	540	164	ISO	Angular Contact Ball Bearings
  7324C	120	260	55	KOYO	Angular Contact Ball Bearings
  73551/73875	139,7	222,25	34,925	Timken	Tapered Roller Bearings
  81128-TV	140	180	31	INA	Thrust Roller Bearings
  BLP205	25		27	FYH	Bearing Units
  F200014	93,8	148	135	Fersa	Tapered Roller Bearings
  HJ-263520,2RS	41,275	55,563	31,75	Timken	Needle Roller Bearings
  LM102949/LM102910	45.242	73.431	19.558	NACHI	Tapered Roller Bearings
  MLE71903CVDUJ74S	17	30	14	SNR	Angular Contact Ball Bearings
  Z-565666.ZL-K-C5	190	290	75	FAG	Cylindrical Roller Bearings
  602	2	7	2.8	ISC	DEEP GROOVE BALL BEARINGS
  1622	.5625	1.3750	.4375	CONSOLIDATED	DEEP GROOVE BALL BEARINGS
  MM75BS110P/4	75	110	15	CONSOLIDATED	ANGULAR CONTACT BALL SCREW SUPPORT BEARINGS
