d - 55 mm

L2 - 19 mm

L3 - 95 mm

s1 - 36,4 mm

A - 64 mm

A1 - 27 mm

B1 - 48,4 mm

D1 - 35 mm

H - 146 mm

H1 - 130 mm

H2 - 102 mm

L - 171 mm

L1 - 106 mm

N - 64 mm

N1 - 25 mm

A2 - 41 mm

Weight - 3,85 Kg

Basic dynamic load rating (C) - 43,6 kN

Basic static load rating (C0) - 29 kN

Fatigue load limit (Pu) - 1,25

Limiting speed - 3 600 r/min

• Model Number: TU 55 FM
• Inner Diameter：55mm Outer Diameter：mm Width：mm
• Type：Bearing Units
• Update date：2025-04-22
• Application:medical equipment,metering pump,Broadcasting System,tapping machine,Cylinder Standard,plastic blow molding,journal lathe,power source,generator,ventilation equipment,hydraulic connector
• Similar models:INA TTUE55 SKF FY55TR NKE RASEY55 INA PME55 SKF FY55WF SKF FYT55TF/VA228 INA RSHE55 INA PTUE55 SKF SY55TF SKF FYJ55KF+HA2311
• BEARING POWER International Trading Co.,Ltd. specialize in TU55FM products，there is large inventory of SKF TU 55 FM . We has been built up long-term cooperation with SKF company, could make a bulk order of the TU 55 FM Which SKF TU55FM is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
