d - 16 mm

d2 max. - 43 mm

d3 - 22 mm

d4 max. - 29 mm

dk - 28,5 mm

h1 - 64 mm

l3 min. - 24 mm

l4 max. - 86 mm

l5 - 8 mm

l7 min. - 21 mm

r1 min. - 0,3 mm

B - 21 mm

C1 max - 15 mm

w - 22 Tolerance h14

Thread (G) - M16 Tolerance 6H

Angle - 15 °

Weight - 0,23 Kg

Basic dynamic load rating (C) - 21,4 kN

Basic static load rating (C0) - 34,5 kN

• Model Number: SILKB16F
• Inner Diameter：16mm Outer Diameter：mm Width：mm
• Type：Plain Bearings
• Update date：2025-12-13
• Application:plastic blow molding,large agricultural machinery,pneumatic,Tool,expectoration machine,ventilation fans,glass processing machine,spring industry,office outdoor camping equipment,industrial supplies,transportation equipment
• Similar models:ISO GE160UK-2RS AST AST5028FIB16 AST AST401625 LS GEH160XT CRAFT SI16T/K AST GEG160ES AST AST11WC16 ISO GE160HCR-2RS CX GE016ES AST AST1116060
• BEARING POWER International Trading Co.,Ltd. specialize in SILKB16F products，there is large inventory of SKF SILKB16F . We has been built up long-term cooperation with SKF company, could make a bulk order of the SILKB16F Which SKF SILKB16F is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  232/530 KCW33+AH32/530	530	980	355	CX	Spherical Roller Bearings
  61805	25	37	7	ISB	Deep Groove Ball Bearings
  6200/HR22Q2	10	30	9	SKF	Deep Groove Ball Bearings
  6315	160	75	37	SKF	Deep Groove Ball Bearings
  7318DF	90	190	43	NACHI	Angular Contact Ball Bearings
  HSS71919-E-T-P4S	95	130	18	FAG	Angular Contact Ball Bearings
  NN3036KC1NAP5	180	280	74	NTN	Cylindrical Roller Bearings
  NUP2226-E-M6	130	230	64	NKE	Cylindrical Roller Bearings
  VEX 8 /NS 7CE3	8	22	7	SNFA	Angular Contact Ball Bearings
  UCFX09E	45			FYH	Bearing Units
  VKBA 3321				SKF	Wheel Bearings
  VKBA 717				SKF	Wheel Bearings
  RL121/2L	1.3750	3.0000	.6875	FAG	CYLINDRICAL ROLLER BEARINGS
  W-1				FBC	THRUST BALL BEARINGS
  HT-11/8				RHP	THRUST BALL BEARINGS
  RHNA162214-RS	22		14	SKF (Old No.)	NEEDLE BEARING
  XWA254201	25	42		SKF (Old No.)	THRUST NEEDLE BEARINGS
  6017MP/5	85	130	22	CONSOLIDATED	DEEP GROOVE BALL BEARINGS
  SNZ-222..23222	110	100	120	CONSOLIDATED	PILLOW BLOCKS
  SSR-20-ZZ	1.2500	2.2500	.5000	CONSOLIDATED	DEEP GROOVE BALL BEARINGS
