d - 95,25 mm

D - 149,225 mm

B - 142,88 mm

C - 71,43 mm

b - 10,5 mm

b1 - 8 mm

d1 - 116,6 mm

dk - 136,906 mm

r1 min. - 1 mm

r2 min. - 1 mm

M - 6,5 mm

da min. - 102,5 mm

da max - 116,6 mm

Da min - 131,4 mm

Da max. - 143,1 mm

ra max. - 1 mm

rb max. - 1 mm

Angle - 5 °

Weight - 7,6 Kg

Basic dynamic load rating (C) - 780 kN

Basic static load rating (C0) - 2360 kN

• Model Number: GEZM312ES-2LS
• Inner Diameter：95,25mm Outer Diameter：149,225mm Width：142,88mm
• Type：Plain Bearings
• Update date：2025-12-12
• Application:journal lathe,plastic rolling,medical equipment,Cleaning equipment,Hydraulic Equipment,Machine Tool Accessories,hydraulic cylinder buffer,clean stationery,dynamic blood pressure,ECG,Grinding and polishing equipment
• Similar models:SKF GEZH312ES SKF GEZH312ES-2RS SKF GEZH312ES-2LS SKF GEZ312ES-2RS SKF GEZM312ES-2LS SIGMA GEZ312ES SKF GEZ312TXE-2LS SKF GEZ312ESX-2LS SKF GEZM312ES-2RS SKF GEZ312ES-2LS
• BEARING POWER International Trading Co.,Ltd. specialize in GEZM312ES-2LS products，there is large inventory of SKF GEZM312ES-2LS . We has been built up long-term cooperation with SKF company, could make a bulk order of the GEZM312ES-2LS Which SKF GEZM312ES-2LS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
