d - 9 mm

D - 24 mm

B - 7 mm

C - 7 mm

d1 - 14,4 mm

d2 - – mm

r1 min. - 11 mm

r2 min. - 11 mm

D1 - 21,2 mm

D2 - 0,3 mm

da min. - 14,3 mm

Da max. - 22 mm

ra max. - 0,3 mm

Weight - 0,014 Kg

Basic dynamic load rating (C) - 3,71 kN

Basic static load rating (C0) - 1,66 kN

Fatigue load limit (Pu) - 0,072

Reference speed - 75000 r/min

Limiting speed - 37000 r/min

Calculation factor (f0) - 13

Calculation factor (kr) - 0,025

• Model Number: E2.609-2Z
• Inner Diameter：9mm Outer Diameter：24mm Width：7mm
• Type：Deep Groove Ball Bearings
• Update date：2025-12-17
• Application:Perfusion device,milling head plug,tooth filling,Vertical pull,Insect Capture,Security Equipment,hydraulic actuator,Food testing,top industry,Industrial,paint paint
• Similar models:CRAFT 609ZZ NTN 609JLLB ISB 609/1320 SKF W609R-2Z SKF E2.609-2Z ISB SS609 ZEN 609-2RS NSK 609 AST F609H-2RS ISB WB1226095
• BEARING POWER International Trading Co.,Ltd. specialize in E2.609-2Z products，there is large inventory of SKF E2.609-2Z . We has been built up long-term cooperation with SKF company, could make a bulk order of the E2.609-2Z Which SKF E2.609-2Z is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
