d - 65 mm

D - 100 mm

B - 35 mm

C - 35 mm

d2 - 78,6 mm

r1 min. - 1,1 mm

r2 min. - 1,1 mm

D1 - 87,5 mm

da min. - 71 mm

da max - 78,6 mm

Da max. - 94 mm

ra max. - 1 mm

Calculation factor (k2) - 0,181

S2 - 5,9 mm

Weight - 1,05 Kg

Basic dynamic load rating (C) - 102 kN

Basic static load rating (C0) - 173 kN

Fatigue load limit (Pu) - 20,4

Limiting speed - 150 r/min

Calculation factor (k1) - 0,071

• Model Number: C4013-2CS5V/GEM9
• Inner Diameter：65mm Outer Diameter：100mm Width：35mm
• Type：Cylindrical Roller Bearings
• Update date：2025-12-10
• Application:sheet industry,Tool,hydraulic connector,linear drive,coupling type,power protection,root canal filling,aerial work equipment,lifting upgrade,Flame Cutting,municipal machinery
• Similar models:SKF C4013-2CS5V/GEM9 SKF C4013V SKF C4013K30V
• BEARING POWER International Trading Co.,Ltd. specialize in C4013-2CS5V/GEM9 products，there is large inventory of SKF C4013-2CS5V/GEM9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the C4013-2CS5V/GEM9 Which SKF C4013-2CS5V/GEM9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
