d - 55 mm

D - 100 mm

B - 33,3 mm

C - 33,3 mm

a - 57 mm

d1 - 63,2 mm

r1 min. - 1,5 mm

r2 min. - 1,5 mm

D1 - 92,3 mm

da min. - 63 mm

Da max. - 91 mm

ra max. - 1,5 mm

Weight - 0,91 Kg

Basic dynamic load rating (C) - 60 kN

Basic static load rating (C0) - 47,5 kN

Fatigue load limit (Pu) - 2

Reference speed - 6300 r/min

Limiting speed - 6300 r/min

• Model Number: 3211ATN9
• Inner Diameter：55mm Outer Diameter：100mm Width：33,3mm
• Type：Angular Contact Ball Bearings
• Update date：2025-12-17
• Application:Pneumatic Control Elements,top industry,Internal thread type,knitted fabrics,electric pump,pump industry,medical treatment,Logistics Equipment,Safety protection,bag machine,test laboratory equipment and accessories
• Similar models:ISO 3211-2RS CRAFT 3211-2RS SKF 3211ATN9 CX 3211 CX 3211-2RS FAG 3211-BD-2HRS-TVH NKE 3211-B-2Z-TV ISB 3211-ZZ FAG 3211-BD-TVH FAG 3211-BD
• BEARING POWER International Trading Co.,Ltd. specialize in 3211ATN9 products，there is large inventory of SKF 3211ATN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the 3211ATN9 Which SKF 3211ATN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
