d - 50 mm
D - 90 mm
B - 58 mm
C - 20 mm
d2 - 62,7 mm
r1 min. - 1,1 mm
r2 min. - 1,1 mm
D1 - 78,7 mm
Da max. - 83 mm
ra max. - 1,1 mm
Weight - 0,85 Kg
Basic dynamic load rating (C) - 26,5 kN
Basic static load rating (C0) - 9,15 kN
Fatigue load limit (Pu) - 0,475
Limiting speed - 4300 r/min
Calculation factor (e) - 0,21
Calculation factor (kr) - 0,04
Calculation factor (Y0) - 3,2
Calculation factor (Y1) - 3
Calculation factor (Y2) - 4,6
Model No. | Inner Diameter | Outer Diameter | Width | Brand | Type |
204KG | 20 | 47 | 14 | Timken | Deep Groove Ball Bearings |
---|---|---|---|---|---|
22248B | 240 | 440 | 120 | NTN | Spherical Roller Bearings |
23168-B-K-MB+AH3168G | 340 | 580 | 190 | FAG | Spherical Roller Bearings |
23038CW33 | 190 | 290 | 75 | AST | Spherical Roller Bearings |
32230-A-N11CA-A250-300 | 150 | 270 | 154 | FAG | Tapered Roller Bearings |
33014/DF | 70 | 110 | 62 | ISB | Tapered Roller Bearings |
BE354525ASYB1 | 35 | 45 | KOYO | Needle Roller Bearings | |
GE15ES-2RS | 15 | 26 | AST | Plain Bearings | |
K15X19X22ZW | 15 | 19 | Timken | Needle Roller Bearings | |
NK 110/40 | 130 | 110 | 40 | SKF | Cylindrical Roller Bearings |
NKJS30 | 30 | 52 | 22 | Timken | Needle Roller Bearings |
RNA4908 | 48 | 62 | 22 | KOYO | Needle Roller Bearings |
SAPP205-14 | 20,6375 | 28,6 | KOYO | Bearing Units | |
W 63805 R-2Z | 37 | 25 | 10 | SKF | Deep Groove Ball Bearings |
ZB1.25.0763.200-1SPPN | 648 | 850 | 67 | ISB | Thrust Ball Bearings |
2213-2RS-TVH | 65 | 120 | 31 | FAG | SELF |
BR-324116 | 1.0000 | IKO | NEEDLE BEARINGS | ||
1207 | 72 | 35 | 17 | FED | DEEP GROOVE BALL BEARINGS |
2216SA | 80 | 140 | 33 | FED | SELF |
109-KSFF | 45 | 75 | 16 | MRC | DEEP GROOVE BALL BEARINGS |
Hot number:KOYO 36686/36620 FAG 6336-M ISO BK0610 KOYO DG4080WRKBSH2C4 Timken K17X21X13 Timken LL327049/LL327010 CX NJ303 E SKF NK14/20 NSK NN3930MB NKE NU430-M CX NUP29/1060 SKF YSPAG 207 Rollway LP1313U New Departure U-30226 CONSOLIDATED 156-R FAG 2217-K-M-C3 FBJ 4303ZZ NACHI 6003-2NSE9 SKF 61809-2RZ IKO BR 243320 U ISO HM905843/10 NMB MBY8CR AST NUP2309 EM FAG N1930K.M1.SP MRC 204SZZCG RIV DLR85 RIV ELP240 New Departure SS77R-2 SKF FPCD1600 CONSOLIDATED 361206-2RS
