d - 395 mm

D - 525 mm

C - 20 mm

H - 65 mm

a - 9,3 mm

d1 - 9,3 mm

d2 - 15 mm

d3 - 9,3 mm

D1 - 486 mm

H1 - 42,5 mm

J - 415 mm

J1 - 505 mm

Weight - 33 Kg

Dynamic load rating radial (C) - 186 kN

Dynamic load rating axial (C) - 300 kN

Static load rating radial (C0) - 655 kN

Static load rating axial (C0) - 2280 kN

Limiting speed - 140 r/min

• Model Number: RTC395
• Inner Diameter：395mm Outer Diameter：525mm Width：20mm
• Type：Complex Bearings
• Update date：2023-10-05
• Application:stamping die and its equipment,tapered grinder,drawing die,garbage disposal,lathe,die casting mold,squeeze machine etc,Optical detection,climb ladder,vertical sawing machine,Cylinder Standard
• Similar models:INA YRTS395 INA YRT395 INA RTC395 INA YRTE395
• BEARING POWER International Trading Co.,Ltd. specialize in RTC395 products，there is large inventory of INA RTC395 . We has been built up long-term cooperation with INA company, could make a bulk order of the RTC395 Which INA RTC395 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
