d - 6 mm

D - 19 mm

B - 6 mm

C - 6 mm

d1 - – mm

d2 - 8,5 mm

r1 min. - 0,3 mm

r2 min. - 0,3 mm

D1 - 15,1 mm

D2 - 16,5 mm

da min. - 8 mm

Da max. - 17 mm

ra max. - 0,3 mm

Weight - 0,0072 Kg

Basic dynamic load rating (C) - 1,53 kN

Basic static load rating (C0) - 0,585 kN

Fatigue load limit (Pu) - 0,025

Reference speed - 85000 r/min

Limiting speed - 56000 r/min

Calculation factor (f0) - 7,9

Calculation factor (kr) - 0,03

• Model Number: W626
• Inner Diameter：6mm Outer Diameter：19mm Width：6mm
• Type：Deep Groove Ball Bearings
• Update date：2025-12-17
• Application:packing equipment,boring bar boring bar,Gear grinding machine,forming machine,luminescent reagent,container finishing,tire industry,cleaning agent,pipe fittings Steel industry,Cutting Machine,lifting equipment Hoisting hoist
• Similar models:ZEN SF626 ISB 626 NTN 6264 SKF 626-2RSLTN9/HC5C3WTF1 NSK 626ZZ1 AST 626H-2RS ISB SS626 KOYO 626 SKF 626/HR22T2 KOYO 6268
• BEARING POWER International Trading Co.,Ltd. specialize in W626 products，there is large inventory of SKF W626 . We has been built up long-term cooperation with SKF company, could make a bulk order of the W626 Which SKF W626 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  54204	22	40	27,4	ISO	Thrust Ball Bearings
  6006N	30	55	13	NTN	Deep Groove Ball Bearings
  6018	90	140	24	NTN	Deep Groove Ball Bearings
  71902 A	15	28	7	ISO	Angular Contact Ball Bearings
  71906 A	30	47	9	ISO	Angular Contact Ball Bearings
  7210 A-UX	50	90	40	CX	Angular Contact Ball Bearings
  7302 A-UO	15	42	26	CX	Angular Contact Ball Bearings
  94675/94113A	171,45	288,925	63,5	KOYO	Tapered Roller Bearings
  B-812	12,7	17,463	19,05	Timken	Needle Roller Bearings
  E-CRO-3209		265	173	NTN	Tapered Roller Bearings
  FLR166ZZ	4,762	10,72	3,175	NTN	Deep Groove Ball Bearings
  FYK 30 WR/VL065	30	33	15,3	SKF	Bearing Units
  PCJY17	17			INA	Bearing Units
  UCF208	40			SNR	Bearing Units
  UKP319+H2319	85		125	NACHI	Bearing Units
  NJ-2340VH	200	420	138	FAG	CYLINDRICAL ROLLER BEARINGS
  HM106T			60	FAG	WITHDRAWAL NUTS
  S8709-88	1.2500	2.5625	.7500	General	DEEP GROOVE BALL BEARINGS
  53422U				STEYR	THRUST BALL BEARINGS WITH SPHERICAL SEATING RING
  4202	15	35	14	CONSOLIDATED	DEEP GROOVE BALL BEARINGS
