d_a - 70 mm

A - 90 mm

B - 71 mm

H - 176 mm

H₁ - 95 mm

H₂ - 32 mm

J - 260 mm

L - 315 mm

H - 28 mm

N₁ - 22 mm

J₆ - 290 mm

J₇ - 32.5 mm

N₄ - max. - 8 mm

A₃ - 80 mm

A₅ - 38.5 mm

b_a - min. - 38 mm

b_a - max. - 70 mm

Basic dynamic load rating - C - 208 kN

Basic static load rating - C₀ - 228 kN

Fatigue load limit - P_u - 25.5 kN

Limiting speed - 3600 r/min

Calculation factor - e - 0.22

Calculation factor - Y₁ - 3

Calculation factor - Y₂ - 4.6

Diameter - d_m - 97.5 mm

Basic Designation bearing - 22214 E

P_a - 20 kN

P_0° - 350 kN

P_55° - 400 kN

P_90° - 240 kN

P_120° - 160 kN

P_150° - 145 kN

P_180° - 215 kN

Mass bearing unit - 11 kg

Diameter - G - 20 mm

• Model Number: SYNT 70 FTS
• Inner Diameter：70mm Outer Diameter：90mm Width：71mm
• Type：Bearing Units
• Update date：2025-04-22
• Application:construction machinery and equipment,water,medical equipment,welding equipment,Spectrum Products,organic raw materials,agricultural testing and analysis equipment and related,gear grinding machine,Forging machine,journal lathe,Vertical machining
• Similar models:KOYO UCTU317-700 SKF SYNT70FTS FYH UCTU316-700 INA RCJTY70 NKE RASE70 NACHI UCTU318+WU700 FYH UCTU211-700 KOYO UCTU314-700 NACHI UCTU209+WU700 INA RMEY70
• BEARING POWER International Trading Co.,Ltd. specialize in SYNT70FTS products，there is large inventory of SKF SYNT 70 FTS . We has been built up long-term cooperation with SKF company, could make a bulk order of the SYNT 70 FTS Which SKF SYNT70FTS is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  15126/15245	31.75	62	19,05	KOYO	Tapered Roller Bearings
  24060 K30CW33+AH24056	300	460	160	CX	Spherical Roller Bearings
  32326	130	280	98,75	NKE	Tapered Roller Bearings
  45392	460	760	240	KOYO	Tapered Roller Bearings
  45BER10X	45	75	16	NSK	Angular Contact Ball Bearings
  6003-2Z/VA208	35	17	10	SKF	Deep Groove Ball Bearings
  7060	300	460	74	KOYO	Angular Contact Ball Bearings
  C 4124 K30V + AH 24124	200	115	93	SKF	Cylindrical Roller Bearings
  ASTT90 F11080	110	115		AST	Plain Bearings
  CX272				CX	Wheel Bearings
  NJ430	150	380	85	CX	Cylindrical Roller Bearings
  RNA 6907 ZW	42	55	36	NBS	Needle Roller Bearings
  RNA6908	48	62	40	ZEN	Needle Roller Bearings
  SF3227	160,000	200,000	20,000	NTN	Angular Contact Ball Bearings
  NAPL209-26	1.6250			IPTCI	PILLOW BLOCKS
  AH3032	160	150		SKF	WITHDRAWAL SLEEVES
  RNA4826	165		35	Torrington	NEEDLE BEARINGS
  FPCC500	5.0000	5.7500	.3750	SKF	DEEP GROOVE BALL BEARINGS
  NF228	140	250	42	SKF	CYLINDRICAL ROLLER BEARINGS
  NA102216	10	22	16	SKF (Old No.)	NEEDLE BEARINGS
