D - 47 mm

d - 24 mm

B - 66 mm

C - 24 mm

B₁ - 40.5 mm

B₂ - 9 mm

B₃ - 18 mm

C₁ - 0.8 mm

d₁ - 36.5 mm

G - M 20x1.5

G₁ - 21 mm

M - 6 mm

M₁ - 4 mm

SW - 10 mm

c - 1 mm

r_1,2 - min. - 1 mm

Basic dynamic load rating - C - 14.7 kN

Basic static load rating - C₀ - 24.5 kN

Fatigue load limit - P_u - 2.9 kN

Maximum dynamic radial loads - F_r - 23.6 kN

Maximum static radial loads - F_0r - 33.5 kN

Limiting speed - 3000 r/min

Mass support roller - 0.4 kg

Recommended tighthening torque - 120 N·m

Grease fitting - NIP A2x7.5

Hexagonal nut - M 20x1.5

Lubrication adapter - AP 10

• Model Number: KRE 47 PPA
• Inner Diameter：24mm Outer Diameter：47mm Width：66mm
• Type：Cylindrical Roller Bearings
• Update date：2025-04-22
• Application:hydraulic connector,industrial equipment,machining,municipal machinery,medical Equipment,horizontal processing,electronic materials,stacker lift platform,chamfering machine etc,linear drive,tapping machine
• Similar models:NSK L476549/L476510 SKF KR47PPA ISO NAO30x47x18 SKF BNTB326247/HB1 NSK 94700/94113 NSK EE470078/470128 NTN 4R3047 ISB FCD92130470 SKF NK47/30 ISO RNAO35x47x16
• BEARING POWER International Trading Co.,Ltd. specialize in KRE47PPA products，there is large inventory of SKF KRE 47 PPA . We has been built up long-term cooperation with SKF company, could make a bulk order of the KRE 47 PPA Which SKF KRE47PPA is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
