d - 30 mm

D - 62 mm

B - 16 mm

C - 19,4 mm

d1 - 40,3 mm

r1 min. - 1 mm

r2 min. - 1 mm

D1 - 55,6 mm

D2 - 54,06 mm

da min. - 35,6 mm

da max - 40,3 mm

Da max. - 56,4 mm

db max. - 40 mm

db min - 35,6 mm

ra max. - 1 mm

Weight - 0,22 Kg

Basic dynamic load rating (C) - 20,3 kN

Basic static load rating (C0) - 11,2 kN

Fatigue load limit (Pu) - 0,475

Limiting speed - 6500 r/min

Calculation factor (f0) - 14

Calculation factor (kr) - 0,025

• Model Number: ICOS-D1B06 TN9
• Inner Diameter：30mm Outer Diameter：62mm Width：16mm
• Type：Deep Groove Ball Bearings
• Update date：2025-04-19
• Application:plastic rolling,Animal Tracking,Solenoid Valves,Hydraulic Rama,shaft milling machine,sterilizers,tapping machine,Broadcasting System,steam Hydraulic control element,Automobile,electric hydraulic lifting platform
• Similar models:INA CSCB065 NTN-SNR 6306 SKF W6306-2RS1 CRAFT 580306 INA RCSMB25/65-FA106 KOYO SA206-18F NKE 16064-MA SKF 61906 Timken 306KDD INA RABRB25/62-FA106
• BEARING POWER International Trading Co.,Ltd. specialize in ICOS-D1B06TN9 products，there is large inventory of SKF ICOS-D1B06 TN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the ICOS-D1B06 TN9 Which SKF ICOS-D1B06TN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
