d - 30 mm

A - 34.1 mm

A₁ - 13.5 mm

A₅ - 29.3 mm

B - 38.1 mm

D_b1 - 74.1 mm

D_b2 - 78.4 mm

J - 82.6 mm

L - 108 mm

H - 12.7 mm

s₁ - 22.2 mm

T - 42 mm

R_G - 1/4-28 UNF

R₁ - 22.7 mm

Basic dynamic load rating - C - 16.3 kN

Basic static load rating - C₀ - 11.2 kN

Fatigue load limit - P_u - 0.475 kN

Limiting speed - 3800 r/min

Mass bearing unit - 1.35 kg

Thread - G₂ - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

• Model Number: FYWR 30 YTHR
• Inner Diameter：30mm Outer Diameter：34,1mm Width：13,5mm
• Type：Bearing Units
• Update date：2025-04-22
• Application:Grinding and polishing equipment,ship special,medical equipment,embroidery cloth,Pneumatic Actuator,vacuum suction cup,knitted fabrics,transportation equipment,labor insurance,Gripper Swing,Display Devices
• Similar models:NKE RMEO30 INA PCF30 INA TCJT30-N ISO UCF306 NACHI UKFCX09+H2309 CRAFT UCF305 NACHI UKT208+H2308 KOYO UCP305 NKE RSHE30-N NACHI UKFC209+H2309
• BEARING POWER International Trading Co.,Ltd. specialize in FYWR30YTHR products，there is large inventory of SKF FYWR 30 YTHR . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYWR 30 YTHR Which SKF FYWR30YTHR is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
