d - 20 mm

A - 29.5 mm

A₁ - 15 mm

A₃ - H14 - 3.2 mm

A₅ - 18.5 mm

B₁ - 43.7 mm

B₄ - 4.75 mm

D_a - H11 - 50.8 mm

D_b - 59 mm

J - 90 mm

H - 112 mm

L - 60.5 mm

H - 12.3 mm

s₁ - 26.6 mm

T - 45.6 mm

Basic dynamic load rating - C - 12.7 kN

Basic static load rating - C₀ - 6.6 kN

Fatigue load limit - P_u - 0.28 kN

Limiting speed - 1800 r/min

Mass bearing unit - 0.27 kg

Thread - G₂ - M6x0.75

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 4 N·m

• Model Number: FYTBK 20 WD
• Inner Diameter：20mm Outer Diameter：29,5mm Width：15mm
• Type：Bearing Units
• Update date：2025-04-22
• Application:Industrial,mobile toilet,Switch,engineering machine,Cylinder Pneumatic Treatment Element,raw material accessories,clean stationery,power tools,storage and transportation equipment,marine analysis and testing equipment,relay
• Similar models:FYH UCT205-14E SNR ESFAE204 KOYO UCSPA206H1S6 FYH UCC204 KOYO SBPFL202-10 AST UCF209-28G5PL NACHI UGFC208 SNR EXFLZ206 KOYO UCFL207-20E SNR EXPE208
• BEARING POWER International Trading Co.,Ltd. specialize in FYTBK20WD products，there is large inventory of SKF FYTBK 20 WD . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYTBK 20 WD Which SKF FYTBK20WD is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.

• Model No.	Inner Diameter	Outer Diameter	Width	Brand	Type
  1205EKTN9+H205	20	52	15	SKF	Self-Aligning Ball Bearings
  210RIN728	533,4	742		Timken	Cylindrical Roller Bearings
  22320B	100	215	73	NTN	Spherical Roller Bearings
  30217UDF	85	150	61	NTN	Tapered Roller Bearings
  45290/45221	57,15	104,775	30,162	Timken	Tapered Roller Bearings
  51103	17,000	30,000	9,000	NTN-SNR	Thrust Ball Bearings
  6217N	85,000	150,000	28,000	SNR	Deep Groove Ball Bearings
  6314ZZE	70	150	35	NACHI	Deep Groove Ball Bearings
  MJ2	50,8	114,3	17,4625	RHP	Deep Groove Ball Bearings
  NF410	50	130	31	CRAFT	Cylindrical Roller Bearings
  NJ210-E-TVP2 + HJ210-E	50	90	20	FAG	Cylindrical Roller Bearings
  PSL 612-331	682,625	1080	660	PSL	Tapered Roller Bearings
  S8PP	19.05	41,275	7,92	Timken	Deep Groove Ball Bearings
  UCFA203	17			KOYO	Bearing Units
  UCFC205	25			NACHI	Bearing Units
  ZKLN5090-2Z	50	90	34	INA	Thrust Ball Bearings
  N1016AKSP	80	125	22	SKF	CYLINDRICAL ROLLER BEARINGS
  KB065XPO	6.5000	7.1250	.3125	KAYDON	FOUR POINT ANGULAR CONTACT BALL BEARINGS
  7607	35	80	21	New Departure	DEEP GROOVE BALL BEARINGS
  NAO10x26x12	10	26	12	SKF	NEEDLE BEARINGS
