d_a - 50 mm

A₁ - 70 mm

A₂ - 15 mm

T - max. - 72.7 mm

B - 65 mm

H - 172.5 mm

H₁ - 65 mm

J - 170 mm

L - 192 mm

D_a - 105 mm

H - 14 mm

a - 5 mm

S - 2.5 mm

J₁ - 77 mm

J₂ - 21 mm

J₃ - 57 mm

J₄ - 49 mm

J₅ - 21 mm

J₆ - 77 mm

N₄ - max. - 6 mm

A₃ - 62 mm

A₅ - 29.5 mm

b_a - min. - 34 mm

b_a - max. - 55 mm

Basic dynamic load rating - C - 104 kN

Basic static load rating - C₀ - 108 kN

Fatigue load limit - P_u - 11.8 kN

Limiting speed - 3300 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 70 mm

Basic Designation bearing - 22210 E

P_a - 15 kN

P₁ - 110 kN

P₂ - 80 kN

P₃ - 110 kN

Mass bearing unit - 4.5 kg

Diameter - G - 12 mm

• Model Number: FYNT 50 L
• Inner Diameter：50mm Outer Diameter：70mm Width：15mm
• Type：Bearing Units
• Update date：2023-10-16
• Application:Machine tool accessories,Industrial Electromechanical,Infrared Technology,ventilation heating equipment,plastic blow molding,printing machinery,manual Tools,filter paper products,crimping tools,small diesel generators,auto tools
• Similar models:NKE PTUEY50 NKE PME50-N SKF FYTB50FM KOYO UCT216-50E FYH UCTU208-500 KOYO UCTU209-500 KOYO UCTH205-15-150 SKF FY50TF/VA228 SKF SYJ50KF+SYJ510 INA PCJ50-N-FA125
• BEARING POWER International Trading Co.,Ltd. specialize in FYNT50L products，there is large inventory of SKF FYNT 50 L . We has been built up long-term cooperation with SKF company, could make a bulk order of the FYNT 50 L Which SKF FYNT50L is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
