d₁ - 65 mm

D - 130 mm

B₁ - 55 mm

d₂ - - 88.5 mm

d₃ - 98 mm

D₁ - - 116 mm

B - 31 mm

B₄ - 14.5 mm

s₁ - 9.6 mm

s₂ - 5.3 mm

r_1,2 - min. - 1.5 mm

d_a - max. - 107 mm

d_b - min. - 80 mm

D_a - max. - 121 mm

B_a - min. - 12 mm

r_a - max. - 1.5 mm

Basic dynamic load rating - C - 220 kN

Basic static load rating - C₀ - 240 kN

Fatigue load limit - P_u - 28 kN

Limiting speed - 2200 r/min

Factor - k₁ - 0.099

Factor - k₂ - 0.127

Mass bearing and adapter sleeve - 2.4 kg

• Model Number: C 2215 KV + H 315
• Inner Diameter：130mm Outer Diameter：65mm Width：55mm
• Type：Cylindrical Roller Bearings
• Update date：2025-04-24
• Application:Display Devices,axle lathe,Gear grinding machine,coal mill,lifting equipment Hoisting hoist,other processing,Vacuum generator,sterilizers,water,metal mold,Broadcasting System
• Similar models:ISB NJ2215 CX NH2215E NACHI NU2215E CYSD NU2215E NKE NUP2215-E-M6 NACHI 22215EXK NKE NJ2215-E-MPA+HJ2215-E KOYO NUP2215 ISO NU2215 CYSD NJ2215E
• BEARING POWER International Trading Co.,Ltd. specialize in C2215KV+H315 products，there is large inventory of SKF C 2215 KV + H 315 . We has been built up long-term cooperation with SKF company, could make a bulk order of the C 2215 KV + H 315 Which SKF C2215KV+H315 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
