d - 30 mm

D - 62 mm

B₁ - 22.2 mm

B - 16 mm

d₁ - - 40.36 mm

d₂ - 37.4 mm

D₁ - - 54.1 mm

D₂ - 58.1 mm

D₃ - 59.61 mm

C - 3.28 mm

b - 1.9 mm

r₀ - 0.6 mm

r_1,2 - min. - 1 mm

L - 540 mm

Tolerance cable length L - ± - 10 mm

d_a - min. - 35 mm

d_b - min. - 35 mm

d_b - max. - 40 mm

D_a - max. - 57 mm

r_a - max. - 1 mm

Cable connector type - Free cable end

Number of pulses per revolution - N - 64

Period accuracy - ± 4 %

Phase shift output signal - 90 °

Tolerance phase shift output signal - ± 30 °

Basic dynamic load rating - C - 19.5 kN

Basic static load rating - C₀ - 11.2 kN

Fatigue load limit - P_u - 0.475 kN

Limiting speed - 7500 r/min

Calculation factor - k_r - 0.025

Calculation factor - f₀ - 14

Mass sensor unit - 0.225 kg

Snap ring - SP 62

• Model Number: BMD-6206/064S2/UA008A
• Inner Diameter：62mm Outer Diameter：30mm Width：22,2mm
• Type：Deep Groove Ball Bearings
• Update date：2025-12-15
• Application:Pneumatic Control Elements,Low-voltage electrical equipment,Display Devices,food safety,Water Monitoring,Industrial,Body shaping,plastic blow molding,Display Devices,root canal filling,Spectrum Products
• Similar models:FAG 6206-2RSR SKF W6206 SKF 6206-2RZTN9/HC5C3WT SNR 6206F600 SNR 6206KEE NACHI 6206NSE KOYO 62062RDC3 SIGMA 6206 SNR 6206NREE ZEN 6206-2RS
• BEARING POWER International Trading Co.,Ltd. specialize in BMD-6206/064S2/UA008A products，there is large inventory of SKF BMD-6206/064S2/UA008A . We has been built up long-term cooperation with SKF company, could make a bulk order of the BMD-6206/064S2/UA008A Which SKF BMD-6206/064S2/UA008A is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
