d - 25 mm

D - 75 mm

H - 28 mm

d₁ - 40.5 mm

D₁ - 49 mm

H₁ - 19 mm

r_1,2 - min. - 0.3 mm

r_3,4 - min. - 0.8 mm

a - 84 mm

J - 58 mm

H - 6.8 mm

d_a - min. - 32 mm

D_a - max. - 49 mm

r_a - max. - 0.6 mm

Basic dynamic load rating - C - 27.6 kN

Basic static load rating - C₀ - 55 kN

Fatigue load limit - P_u - 2 kN

Limiting speed - 5600 r/min

Preload - 1920 N

Frictional moment - 0.2 N·m

Static Axial rigidity - 770 N/micron

Mass bearing - 0.72 kg

Required attachment bolt size - M6

Number of attachment bolts - 8

• Model Number: BEAM 025075-2RZ/PE
• Inner Diameter：25mm Outer Diameter：75mm Width：28mm
• Type：Thrust Ball Bearings
• Update date：2025-04-25
• Application:electromyography machine,hydraulic cylinder,Cylinder Pneumatic Treatment Element,electric pump,stamping die and its equipment,other accessories,Hair styling device,multi-knife lathe,Machine Tool Accessories,chemical,Dental Equipment
• Similar models:SKF BEAM025075-2RS SKF BEAM025075-2RZ SKF BEAM025075-2RS/PE SKF BEAM025075-2RZ/PE
• BEARING POWER International Trading Co.,Ltd. specialize in BEAM025075-2RZ/PE products，there is large inventory of SKF BEAM 025075-2RZ/PE . We has been built up long-term cooperation with SKF company, could make a bulk order of the BEAM 025075-2RZ/PE Which SKF BEAM025075-2RZ/PE is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
