d - 40 mm

D - 90 mm

B - 33 mm

C - 33 mm

d2 - 53,7 mm

r1 min. - 1,5 mm

r2 min. - 1,5 mm

D1 - 79,2 mm

da min. - 49 mm

Da max. - 81 mm

ra max. - 1,5 mm

Weight - 0,93 Kg

Basic dynamic load rating (C) - 54 kN

Basic static load rating (C0) - 16 kN

Fatigue load limit (Pu) - 0,82

Reference speed - 14000 r/min

Limiting speed - 10000 r/min

Calculation factor (e) - 0,4

Calculation factor (kr) - 0,05

Calculation factor (Y0) - 1,6

Calculation factor (Y1) - 1,6

Calculation factor (Y2) - 2,4

• Model Number: 2308ETN9
• Inner Diameter：40mm Outer Diameter：90mm Width：33mm
• Type：Self-Aligning Ball Bearings
• Update date：2025-12-11
• Application:transistor fittings,surgical instruments,medical equipment,experimental equipment,Internal thread type,cooling system,diagnostic test paper,tire industry,wire industry,Vertical pull,marine analysis and testing equipment
• Similar models:NACHI 2308 SNR 2308EEG15 KOYO 2308 SKF 2308E-2RS1TN9 NSK 2308K FAG 2308-2RS-TVH NSK 2308 ISB 2308TN9 CX 2308K+H2308 CX 2308K
• BEARING POWER International Trading Co.,Ltd. specialize in 2308ETN9 products，there is large inventory of SKF 2308ETN9 . We has been built up long-term cooperation with SKF company, could make a bulk order of the 2308ETN9 Which SKF 2308ETN9 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
