(dimensions in mm)

Bearing Type - Cast iron housing

Dynamic Load Rating (Cr) - 34,120

Static Load Rating (Cor) - 21,277

Shaft Dia. (Fw) - 45.0000

Housing Width (b) - 108.0000

Mounting Hole Center-to-Center (e) - 148.0000

Housing Length (a) - 188.0000

Housing Base Thickness (g) - 15.0000

Bearing Inner Race Width (Bi) - 49.0000

Bearing Inner Race Width - Short Side (n) - 19.0000

Bearing Inner Race Width - Extended Side (m) - 30.0000

Mounting Bolt Size - 14.0000

Housing Number - FL 209E

Mounting Hole Dia. (s) - 15.0000

Flange Assembly Height (Z) - 52.0000

Flange Height (l) - 38.0000

Mounting Base to Bearing Center (i) - 22.0000

Weight (g) - 1,894.00

Material - Cast iron housing, chrome steel bearing

Also available with eccentric locking collar.

Medium Duty, Heavy Duty and other available types are described in the Bearing Types information.

Various seal options and plated housing options are described in the Nomenclature and Bearing Types information.

• Model Number: UCFL 209
• Inner Diameter：45mm Outer Diameter：mm Width：mm
• Type：Bearing Units
• Update date：2025-12-11
• Application:engineering machine,agricultural testing and analysis equipment and related,Pneumatic Control Elements,coupling type,laser devices,Handling machinery and various industrial machinery,embroidery cloth,bag machine,preservation equipment,granulator,Machine tool accessories
• Similar models:SNR USPAE209 SNR UCPG209 CRAFT UCT209 FYH UCPH209-27 KOYO UCC209 FYH NAPK209-27 FYH NAPK209-26 SNR EST209+WB SNR USEHE209 SNR EXFCE209
• BEARING POWER International Trading Co.,Ltd. specialize in UCFL209 products，there is large inventory of AST UCFL 209 . We has been built up long-term cooperation with AST company, could make a bulk order of the UCFL 209 Which AST UCFL209 is the most authentic, must choose BEARING POWER, what a whole variety, reasonable price, guaranteed quality, prompt delivery via Global express.Any inquiry, never hesitate to E-mail or call +86-022-58519721 to contact us.
